Rohacell – HF
Rohacell – HF
With its extremely low dielectric constants and particularly favorable transmission properties in the high frequency region, ROHACELL® HF has been specially designed for antenna applications.
Applications range from miniature antennas in cell phones to large fixed ship-based and stationary antenna structures. Other advantages of ROHACELL® HF in such applications are its extremely fine cell structure that ensures minimal resin uptake, and problem-free compatibility with metallic facing materials due to the absence of corrosive effects.
ROHACELL® HF is also used in radomes and mammography plates.
Fine-cell materials can be processed by hand lay-up, prepreg, or vacuum infusion techniques at pressures up to 0.3 MPa and temperatures up to 130°C.
Sales Range For ROHACELL® HF in mm
ROHACELL® HF | Size [mm] | Standard sheet thickness [mm] |
31 HF | 2500 x 1250 | 1 – 120 |
51 HF | 2500 x 1250 | 1 – 110 |
71 HF | 2160 x 1100 | 1 – 95 |
Thickness tolerance +/- 0.008 inch, other tolerances available on request.
All dimension ranges presented in these tables are standard.
We stock a limited range of Rohacell HF, and import to order specifications. For stock availability, please contact us below.
